16-Port USB-PS/2 IP KVM with 16 USB Cables


This Sku combines following items:

CS1716i :16-port 1 user IP USB/PS2 KVM Switch

2L5201U : 4 ft. USB KVM Cable

2L5202U : 6 ft. USB KVM Cable

2L5203U : 10 ft. USB KVM Cable

Package Contents

  • 1x CS1716i
  • 4x 2L5201U - 4ft. USB KVM cable
  • 8x 2L5202U - 6ft. USB KVM cable
  • 4x 2L5203U - 10ft. USB KVM cable
  • Hardware

  • 16-port remote access KVM switch - monitor and control up to 16 computers from a single KVM console
  • Daisy chain up to 15 additional units - control up to 256 computers
  • Auto-sensing of station's position on daisy chained installations; no need for manual dip switch setting; front panel LED indicates station's position
  • Multiplatform support - Windows, Linux, Mac, and Sun
  • Dual Interface - supports PS/2 or USB keyboard and mouse computers
  • Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
  • Superior video quality - up to 2048 x 1536; DDC2B for the local console; up to 1600 x 1200 @ 60Hz / 24 bit color depth for remote sessions
  • BIOS-level access
  • Mouse DynaSync
  • Rack mountable in a 19" system rack


  • Panel array mode enables user to monitor multiple servers from single screen at the same time - each selected server's video output appears in a separate panel - users can easily select the number of panels to view
  • Event Logging
  • Up to 32 concurrent logins
  • Broadcast mode; operations simultaneously performed on all selected computers(software installation, system-wide shutdown, etc.)
  • Port names automatically reconfigured when station sequence is changed
  • Message board allows logged in users to communicate with each other, and allows a user to take exclusive control of the KVM functions
  • On-screen keyboard with multilanguage support


  • Secure keyboard/mouse/video transmission via RC4 128bit encryption
  • 128bit SSL browser access
  • Two level password secuirty - up to 64 user accounts with separate profiles for each
  • External(remote) authentication support: RADIUS, LDAP, LDAPS, MS Active Directory
  • Support for IP/Mac Filter
  • Local and remote access logged and authenticated
