8-Port 19in. Single Rail USB/PS2 LCD KVM w/ Peripheral Sharing & 8 USB KVM Cables


CL5708NUKIT

This Sku combines following items:


1-CL5708N: 8-Port LCD KVMP


2-2L5201U 4 ft. USB KVM Cable


4-2L5202U 6 ft. USB KVM Cable


2-2L5203U 10 ft. USB KVM Cable

Package Contents

  • 1 x CL5708 KVMP Switch with standard Rack Mounting Kit
  • 2 x 2L5201U
  • 4 x 2L5202U
  • 2 x 2L5203U
  • 1 x 5-in-1 console cable
  • 1 x Firmware Upgrade Cable
  • 1 x Power Cord (6ft.)
  • 1 x Grounding Wire (4ft.)
  • 1 x User Manual
  • 1 x Quick Start Guide
  • Space saving technology—up to two consoles (one bus) control up to 8/16 computers
  • Extra console port—manage computers in the LCD KVM switch from an external console
  • Dual interface—supports PS/2 and USB keyboards and mice in the KVM Ports
  • Supports external USB mouse
  • USB peripheral support for attached computers
  • Convenient station and port selectors, each with two 7-segment LED displays
  • Dedicated Hotkey Mode and OSD Invocation Keys
  • Convenient computer selection via mouse-driven OSD
  • Console lock— locks the console draw to remain securely locked away when not in use
  • Daisy chain up to 31 additional KVM switches to control up to 256 computers
  • No software required
  • Hot pluggable—add or remove computers without powering down the switch
  • OSD port list automatically expands when new stations are added
  • Auto Scan Mode enables continuous monitoring of user-selected computers
  • Security—Administrator/User password authorization for enhanced security protection
  • Two level password security—only authorized users can view and control computers
  • OSD screen automatically adjusts to resolution changes
  • Supports Windows, Sun, Linux, Mac, Unix, Netware, AIX (RS6000), and DOS 6.2 and later
  • Standard 105-key keyboard
  • Video resolutions up to 1280 x 1024@ 75Hz.
  • Upgradeable firmware—simultaneously upgrade the firmware for all KVM switches on the
  • chain via the chaining bus



Physical Properties
Case Dimension36.0x 12.0x 36.0 in.
Case Weight46.0 lb.
Case Qty
