16-Port USB-PS/2 KVM with 16 USB Cable


CS1716AUKIT

This Sku combines following items



1 x CS1716A 8-port USB/PS2 Combo KVMP Switch


4 x 2L5201U 4 ft. USB KVM Cable


8 x 2L5202U 6 ft. USB KVM Cable


4 x 2L5203U 10 ft. USB KVM Cable

Package Contents

  • 1 x CS1716A KVM Switch with
  • 4 x 2L5201U
  • 8 x 2L5202U
  • 4 x 2L5203U
  • 1 x Console Cable
  • 1 x Firmware Upgrade Cable
  • 1 x Standard Rack Mounting Kit
  • 1 x Grounding Wire
  • 1 x Foot Pad Set (4 pcs)
  • 1 x Power Adapter
  • 1 x User Manual
  • 1 x Quick Start Guide
  • A single console controls up to 16 computers
  • Daisy-chain up to 31 additional units – control up to 256 computers from a single console
  • Front accessible USB port allows each computer to access USB peripherals*
  • Dual Interface –supports computers and console with PS/2 or USB keyboards and mice
  • Multiplatform support – Windows 2000/XP/Vista, Linux, Mac, and Sun
  • Display Emulation Technology – stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
  • Auto PS/2 and USB interface detection
  • USB / PS/2 keyboard and mouse emulation – computers boot even when the console focus is elsewhere
  • Video resolution up to 2048 x 1536; DDC2B
  • No software required – convenient computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menus
  • Auto-senses station's position on daisy-chained installations; no need for manual dip switch setting; front panel led indicates station's position
  • Port names automatically reconfigured when station sequence is changed
  • Two level password security; only authorized users view and control computers; up to four users and an administrator with separate profiles for each
  • Auto Scan feature for monitoring user-selected computers
  • Broadcast mode; operations simultaneously performed on all selected computers
  • Hot pluggable – add or remove computers without having to power down the switch
  • Buzzer on/off via hotkey and OSD
  • Firmware upgrades to all the chained KVM switches at the same time via the daisy-chain cable
  • Rack mountable in 19" system rack (1U)
Physical Properties
Unit Weight10.02
Case Qty3
Case Weight30.06 lb.
Case Dimension4.6 x 9.25 x 21.6 in.
