HDMI HDBaseT-Lite Transmitter with EU Wall Plate (4K@40m) (HDBaseT Class B)


Discontinued Suggested Replacement Model
VE1801EUT
MSRP: Quote Upon Request
  • Extends HDMI signals with superior video quality over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
    • 4K up to 40 m
    • 1080p up to 70 m
  • HDMI 1.4 (3D, Deep color, 4K); HDCP 2.2 compliant
  • Designed to mount in a one-gang junction box
  • Supports RS-232 channel transmission
4K
HDBaseT
HDMI

ATEN VE1801EUT is a transmitter designed to reliably send 4K signals up to 40 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. With EU Wall Plate design, the VE1801EUT can be conveniently mounted in a one-gang junction box. For HDMI signal transmission, it supports 3D, Deep Color, and embedded HD lossless audio formats.

The compact wall plate design does away with bulky cables, allowing a neat and convenient installation. Therefore, VE1801EUT is specifically designed for use in meeting rooms, digital educational environment or wherever needed to meet application requirements.

Package Contents

  • 1x VE1801EUT HDMI HDBaseT-Lite Transmitter with EU Wall Plate (4K@40m)
  • 4x Foot Pads
  • 1x Faceplate
  • 2x Pan Head Screws
  • 4x PF Screws
  • 1x Power Adapter
  • 1x RS-232 Terminal Block (3-pin)
  • 1x Power Terminal Block (2-pin)
  • 1x User Instructions
  • Extends HDMI signals with superior video quality over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
    • 4K up to 40 m
    • 1080p up to 70 m
  • HDMI 1.4 (3D, Deep color, 4K); HDCP 2.2 compliant
  • Designed to mount in a one-gang junction box
  • Supports RS-232 channel transmission
  • Consumer Electronic Control (CEC) allows interconnected HDMI devices to communicate and respond to a single remote control
  • HDBaseT Anti-jamming – resists signal interference during high-quality video transmission using HDBaseT technology
  • LED indication of device status
  • Supports widescreen format
  • Built- in 8KV / 15 KV ESD protection
  • Plug-and-play
Video Input
Interfaces1 x HDMI Type A Female (Black)
Impedance100Ω
Max. Distance3 m
Video
Max. Data Rate10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock340 MHz
ComplianceHDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
Max. Resolutions / DistanceUp to 4K@35m (Cat 5e/6) / 40m (Cat 6a/ATEN 2L-2910 Cat6);
1080p@60m (Cat 5e/6) / 70m (Cat 6a/ATEN 2L-2910 Cat6)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio
Input1 x HDMI Type A Female (Black)
Control
RS-232 Channel1 x Terminal Block, (3 pole, Green)
Connectors
Unit To Unit1 x RJ-45 Female
Power1 x Terminal Block (2 pole, Green)
Power ConsumptionDC5V:1.749W:8BTU
Environmental
Operating Temperature0 - 40°C
Storage Temperature-20 - 60°C
Humidity0% - 80% RH, Non-condensing
Physical Properties
HousingMetal
Weight0.17 kg ( 0.37 lb )
Dimensions (L x W x H)6.86 x 4.44 x 4.10 cm
(2.7 x 1.75 x 1.61 in.)
Faceplate Dimensions (L x W x H)8.60 x 8.60 x 1.60 cm
(3.39 x 3.39 x 0.63 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
