Single Rail 8-Port DVI FHD LCD KVM Switch


The CL6708MW brings additional versatility to ATEN’s line of LCD KVM Switches with its native DVI compatibility. Building on ATEN’s renowned, space-saving approach to KVM switches – which integrates an LCD panel, full keyboard, and touchpad into a streamlined, 1U housing – the CL6708MW is a highly-scalable LCD KVM switch which features the ability to control up to 64 computers by cascading 8 additional CS1768 8-port KVM switches.

Featuring an integrated 17.3" LED-backlit LCD panel capable of full HD 1080p video – greater clarity than typical analog interfaces – the CL6708MW incorporates the YUV video format for greater compatibility with high-definition signals (e.g. NVR sources). Similarly, the CL6708MW is High-Bandwidth Digital Content Protection (HDCP) compatible, making it well-suited for use with content-protected media in corporate, educational, and commercial settings.

To further enhance usability, ATEN’s LED illumination light is included to ensure keyboard and touchpad visibility in low-light conditions.


Package Contents

  • 1x CL6708MW Single Rail 8-Port DVI FHD LCD KVM Switch with Standard Rack Mount Kit
  • 2x KVM Cable (DVI-D, USB, Audio; 1.8m/6ft)
  • 1x Power Cord
  • 1x Firmware Upgrade Cable
  • 1x User Instructions
  • Integrated KVM with a 17.3” Widescreen DVI Full HD LCD monitor
  • Single rail, sliding housing with top and bottom clearance for smooth operation in a 1U rack
  • Controls eight Single Link DVI computers
  • Supports an external console with DVI video port
  • Exclusive LED illumination light - designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
  • KVM port extendable via one-level cascade (up to 8 additional CS1768 8-port KVM switches)
  • Computer selection via front panel pushbuttons, hotkeys, and multilingual on-screen display (OSD)
  • Broadcast mode – allows you to send commands from the console to all computers to perform operations simultaneously
  • Firmware upgradable
  • Supports YUV video format for greater compatibility
  • DVI monitor support – fully compliant with DVI specifications
  • Video DynaSync™ – exclusive ATEN technology eliminates boot-up display problems and optimizes responsiveness when switching between ports
    Note: Video DynaSync™ only works with digital video sources
  • HDCP-compatible for hassle-free content-protected media playback
  • Superior video quality – 1920 x 1080 @ 60Hz; DDC2B
  • Adjustable depth to fit within the rack
  • Audio support for connecting speakers
  • Auto Scan Mode for monitoring all computers
  • Multiplatform support – Windows, Linux, Mac, Sun
  • Console lock – enables the console drawer to remain securely locked away in position when not in use

    More information about "Easy Rack Mounting"...

Single Rail 8-Port DVI FHD LCD KVM Switch

Computer Connections
Port SelectionOSD, Hotkey, Pushbutton
External Console Ports1 x DVI-I Female, 2 x USB Type A Female, 1 x Mini Stereo Jack Female
External Mouse Port1 x USB Type-A Female
KVM Ports8 x DVI-I Female, 8 x USB Type A Female, 8 x Mini Stereo Jack Female
Firmware Upgrade1 x RJ-11 Female
Power1 x IEC60320/C14
Reset1 x Semi-recessed Pushbutton
Power1 x Rocker Switch
Firmware Upgrade1 x Slide Switch
LCD Adjustment4 x Pushbutton
LCD On/Off1 x Pushbutton
Port Selection8 x Pushbutton
Online8 (Orange)
Selected8 (Green)
Power1 x KVM Power(Dark Green)
1 x LCD Power(Orange)
Lock1 x Num Lock (Green)
1 x Caps Lock (Green)
1 x Scroll Lock (Green)
Panel Spec
LCD Module17.3" TFT-LCD
Pixel Pitch0.1989 mm x 0.1989 mm
Support Color262144 colors
Contrast Ratio650:1
Luminance300 cd/m²
Response time8 ms
Viewing Angle140° (H), 120° (V)
Keyboard / MouseUSB
Video1920 x 1080 @ 60 Hz; DDC2B
Scan Interval1–255 sec.
Maximum Input Power Rating100–240 V AC, 50/60 Hz, 1 A
Power Consumption110V, 29.26W ; 220V, 28.82W
Operating Temperature0–40°C
Storage Temperature-20–60°C
Humidity0–80% RH, Non-condensing
Physical Properties
HousingMetal + Plastic
Weight12.70 kg ( 27.97 lb )
Dimensions (L x W x H)48.00 x 68.92 x 4.40 cm
(18.9 x 27.13 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
