HDMI Cat 5 Extender (1080p@40m)
VE800A
- Uses Cat 5e cable to extends the distance between HDMI source and HDMI display
- Extend 1080p by 40 m; extend 1080i (HDTV) by 60 m
- HDMI (3D, Deep Color); HDCP Compatible
- 8 segment equalization adjustment switch optimizes display quality
Note: The images are for reference only. The printing on the device may differ due to product enhancement.
MSRP:
Quote Upon Request
The VE800A HDMI Extender extends your HDMI display up to 60 m away from your HDMI source using one Cat 5/6 cable. ATEN’s VE800A incorporates new technology that allows the A/V signals to be transmitted over a single Cat 5e cable. DDC port is provided for the ability to use the display’s EDID by simply connecting another Cat 5/6 cable. The VE800A supports HDMI features such as 3D and Deep Color to give you the picture perfect viewing experience you desire.
Package Contents
- 1x VE800AT HDMI Extender
- 1x VE800AR HDMI Extender
- 2x Power Adapters
- 1x Mounting Kit
- 1x User Instructions
- Extends the distance between HDMI source and HDMI display
- Uses Cat 5/6 cable to connect the local and remote units
- Extend 1080p by 40 m; extend 1080i (HDTV) by 60 m
- Superior video quality – 1920 x 1200, up to 1080p
- HDMI (3D, Deep Color); HDCP Compatible
- Supports Dolby True HD and DTS HD Master Audio
- 8 segment equalization adjustment switch optimizes display quality
- DDC compatible
Function | VE800AR | VE800AT |
Video Output | ||
Interfaces | 1 x HDMI Type A Female (Black) | N/A |
Impedance | 100 Ω | N/A |
Max. Distance | 3 m | N/A |
Video Input | ||
Impedance | N/A | 100 Ω |
Interfaces | N/A | 1 x HDMI Type A Female (Black) |
Max. Distance | N/A | 3 m |
Video | ||
Max. Data Rate | 6.75 Gbps (2.25 Gbps Per Lane) | 6.75 Gbps (2.25 Gbps Per Lane) |
Max. Pixel Clock | 225 MHz | 225 MHz |
Compliance | HDMI (3D, Deep Color) HDCP Compatible | HDMI (3D, Deep Color) HDCP Compatible |
Max. Resolutions / Distance | Up to 1080p@40m; 1080i@60m | Up to 1080p@40m; 1080i@60m |
Audio | ||
Output | 1 x HDMI Type A Female (Black) | N/A |
Input | N/A | 1 x HDMI Type A Female (Black) |
Connectors | ||
Power | 1 x DC Jack | 1 x DC Jack |
Power Consumption | DC5V:0.61W:3BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. | DC5V:0.9W:4BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
Environmental | ||
Operating Temperature | 0 - 50°C | 0 - 50°C |
Storage Temperature | -20 - 60°C | -20 - 60°C |
Humidity | 0 - 80% RH, Non-Condensing | 0 - 80% RH, Non-Condensing |
Physical Properties | ||
Housing | Metal | Metal |
Weight | 0.16 kg ( 0.35 lb ) | 0.16 kg ( 0.35 lb ) |
Dimensions (L x W x H) | 9.00 x 5.50 x 2.20 cm (3.54 x 2.17 x 0.87 in.) | 9.00 x 5.50 x 2.20 cm (3.54 x 2.17 x 0.87 in.) |
Carton Lot | 5 pcs | 5 pcs |
Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
