VGA/Audio/RS-232 Cat 5 Repeater with Dual Output (1600 x 1200@150m)
Discontinued Suggested Replacement Model
VB552
- Uses Cat 5e cable to extend audio/video signal
- Extends the transmission range an extra 150m
- High-quality video - up to 1920x1200@60Hz at 30m, 1600x1200@60Hz at 150m, 1280x1024@60Hz at 200m
- Audio and serial enabled
The VB552 VGA Over Cat 5 Repeater +Audio is an audio/video signal extension device which is compatible with ATEN Cat 5 Audio/Video splitters. The VB552 extends the audio/video transmission range an extra 150m over Cat 5e (or higher) cables. The use of an additional repeater means the audio/video signals can be transmitted over even longer distances, up to 450m.
Furthermore, for longer distance installations where video signals may degrade, the VB552 has adjustable video gain and compensation controls to provide the sharpest video quality possible. An IR remote control also provides picture control at the remote site.
Rack-mountable, with two RS-232 channels on the unit for selection, and support for high video resolutions, the VB552 is the perfect solution to extend the range of your A/V and serial transmissions in any installation environment requiring VESA FDMI mount standards.
Package Contents
- 1x VB552 VGA Over Cat 5 Repeater + Audio
- 1x Power Adapter
- 1x Infrared Remote Control Handset
- 1x Infrared Receiver
- 1x IR Receiver Holder
- 1x Mounting Kit
- 1x User Instructions
- Uses Cat 5e cable to extend audio/video signal
- Extends the transmission range an extra 150m
- High-quality video - up to 1920x1200@60Hz at 30m, 1600x1200@60Hz at 150m, 1280x1024@60Hz at 200m
- Audio and serial enabled
- Two gain control modes for sharpest picture quality
- Video gain and compensation adjustable via OSD
- IR receiver for quick and easy video quality adjustment
- IR remote control for screen on/off and video adjustment at remote site
- Provide a RS-232 channel for selection*
- Follows VESA FDMI mount standard
- Supports DDC for the local monitor
- Supports VGA, SVGA, XGA, SXGA, UXGA and multisync monitors
- For use in combination with VS1504/VS1508 Audio/ Video splitter
* Only one RS-232 channel can be selected at a time
Video Output | |
Interfaces | 2 x HDB-15 Female (Blue) |
Impedance | 75 Ω |
Max. Distance | 1.8 m |
Video | |
Max. Bandwidth | 300 MHz |
Max. Resolutions / Distance | Up to 1920 x 1200@60Hz@30m; 1600 x 1200@60Hz@150m |
Audio Outputs | |
Interfaces | 2 x Mini Stereo Jack Female (Green) |
Control | |
RS-232 | Connector: 2 x DB-9 Male (Black) |
Connectors | |
Power | 1 x DC Jack (Black) |
Power Consumption | DC5.3V:4.92W:23BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
Environmental | |
Operating Temperature | 0 - 50°C |
Storage Temperature | -20 - 60°C |
Humidity | 0 - 80% RH, Non-Condensing |
Physical Properties | |
Housing | Metal |
Weight | 0.35 kg ( 0.77 lb ) |
Dimensions (L x W x H) | 13.90 x 8.80 x 2.86 cm (5.47 x 3.46 x 1.13 in.) |
Carton Lot | 5 pcs |
Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
