4-Port USB 4K HDMI KVMP™ Switch (Cables included)

New
CS784H

Streamline your desktop with seamless 4K control all from one keyboard, mouse, and monitor.

Superior video quality – up to 4096 x 2160 @ 60 Hz
Supports Video DynaSync™
All HDMI & USB cables included
Computer selection via remote port selector, hotkeys, and USB mouse

MSRP: Quote Upon Request

The CS784H is a 4-port desktop KVM switch designed for those who demand a streamlined workflow and uncompromising visual quality across multiple systems. It enables fast, reliable switching between four HDMI computers with up to 4K DCI resolution, while sharing a single keyboard, monitor, mouse, audio output, and USB peripherals through one KVM console. With multiple switching methods – including pushbuttons, hotkeys, and a remote port selector – the CS784H is the perfect companion for desktop setups in offices, content creation, remote work, design, and more.

Space-Efficient Desktop Setup

The CS784H simplifies control of up to four HDMI computer systems by sharing a single keyboard, monitor, and mouse from one KVM console, delivering a clutter-free and organized desktop workspace.

Superior Visual Clarity

The KVM switch is designed to deliver exceptional visual performance, supporting 1080p@60, 4K@60, and up to 5120×1440@60.

USB Peripheral Sharing

Media and data sharing between computers is fast and effortless via plug-n-play connection (e.g. hard drive, flash drive, printer, etc) to the USB ports on the KVM switch.

Flexible Port Selection

Port switching is quick and flexible via pushbuttons, hotkeys, or the remote port selector – whichever best fits your workflow.

All Essentials Packed. No Extras Needed.

Everything you need is included – 4 HDMI cables, 2 USB 2.0 A to B cables, 1 power adapter, and 1 remote port selector (wired switch button) – for instant setup.

Applications

The CS784H enables centralized control of up to 4 HDMI computers via one keyboard, mouse, and monitor, delivering a tidy and efficient desktop workspace where multitasking is streamlined and cable clutter is minimized.

Talk to Our Experts

If you prefer to have ATEN contact you, please complete the form and a representative will be in touch with you shortly

The ATEN CS784H 4-Port USB 4K HDMI KVMP. Switch enables users to control up to 4 computers with a single USB keyboard, mouse and HDMI monitor. The CS784H effectively reduces desktop clutter and minimizes the cost and complexity of multi-system setups.

The CS784H provides multiple port selection methods, including a remote port selector, hotkeys, and mouse wheel switching to engineer for maximum flexibility. In addition, the CS784H features USB peripheral sharing, allowing users to share USB 2.0 devices such as printers, storage drives, or scanners, among all connected computers.

The CS784H supports resolutions up to 4096 x 2160 @ 60Hz and ultra-wide to 5120 x 1440 @ 60Hz, ensuring optimized display resolution with exceptional detail and clarity in all conditions. With ATEN’s patented Video DynaSync. technology, the CS784H ensures optimal resolution and consistent window layout during port switching for smooth multi-system workflows.

Designed for easy deployment, the CS784H includes all the necessary HDMI and USB cables and adapters, providing a plug-and-play experience right out of the box. Designed for SOHO environments, remote workstations, or office setups, the CS784H delivers efficient multi-computer control with exceptional video fidelity and operational convenience.

Single USB keyboard and mouse control up to 4 PCs, simplifying cables and reducing the cost of multi-computer setups
Superior video quality – up to 4096 x 2160 @ 60 Hz, 5120 x 1440 @ 60Hz
Exclusive ATEN technology ensures optimal resolution and consistent window layout during port switching for smooth multi-system workflows
Computer selection via remote port selector, hotkeys, and USB mouse
Multiplatform support – Windows, Mac, and Linux
USB peripheral sharing
All HDMI / USB cables and adapter included
Power-on detection automatically switches to the next active computer
Supports most gaming / multimedia keyboards and multifunction mice with emulation or bypass
Auto-scan function allows continuous monitoring of connected systems
Plug and play – no software installation or configuration required
Supports hot-plugging
Firmware upgradeable

Computer Connections	4
Port Selection	Hotkey, Pushbutton, Mouse, Remote Port Selector
Connectors
Console Ports	2 x USB Type A Female 1 x HDMI Female (Black) 1 x 3.5mm Audio Jack Female (Green; 1 x front)
KVM (Computer) Ports	4 x USB2.0 Type B Female (Blue) 4 x HDMI Female (Black)
Power	1 x DC Jack
USB Hub	2 x USB2.0 Type A Female (White; 2 x front)
Switches
Selected	4 x Pushbutton
LEDs
On Line /Selected	4 (Orange)
Emulation
Keyboard / Mouse	USB
Video	Up to 4096 x 2160 @ 60Hz, 5120 x 1440 @ 60Hz
Scan Interval	1-99 Seconds (Default: 5 sec.)
Power Consumption	DC5V:1.73W:34BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Environmental
Operating Temperature	0-40°C
Storage Temperature	-20-60°C
Humidity	0-80% RH, Non-condensing
Physical Properties
Housing	Metal, Plastic
Weight	0.47 kg ( 1.04 lb )
Dimensions (L x W x H)	20.23 x 8.17 x 2.50 cm (7.96 x 3.22 x 0.98 in.)
Note	For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
